The HP Metal Curtain Wall System is a premium insulated sandwich panel solution engineered for high-rise buildings, industrial facilities, and public infrastructure. Featuring a non-combustible rock wool core (A1 fire rated up to 4 hours) and PVDF-coated aluminum face sheets, this prefab curtain wall system delivers exceptional thermal insulation (U-value as low as 0.32 W/m²·k), superior wind load resistance (Grade 9), and outstanding structural rigidity with surface flatness ≤0.5mm/m.
As a factory-direct metal cladding manufacturer, we provide complete turnkey solutions from design to installation. Our interlocking panel system enables rapid on-site assembly, reducing construction time by up to 30% compared to traditional aluminum veneer systems. Available in 50-120mm thicknesses, custom RAL colors, and multiple coating finishes (PVDF/LUXACOTE/POLYESTER), the HP system meets GB/T 23932-2009 and JGJ 133-2001 standards. Free samples available. 24/7 global technical support.
Superior FlatnessSurface flatness ≤0.5mm/m. Eliminates oil-canning effect.Flawless Finish
Fast InstallationInterlocking dry-hung assembly. 60% faster than aluminum veneer systems.Quick Install
Product Overview – HP Metal Curtain Wall System
The HP Metal Curtain Wall System is a premium insulated sandwich panel solution engineered for high-rise buildings, industrial facilities, and public infrastructure. Featuring an A1 fire rated non-combustible rock wool core with up to 4 hours fire resistance (150mm), this system delivers exceptional thermal insulation with U-value as low as 0.32 W/m²·k, reducing energy costs by up to 25%. With Grade 9 wind load resistance, it withstands 12+ typhoon-force winds, making it the ideal choice for demanding building envelope projects worldwide.
Why Choose HP Metal Curtain Wall System?
A1 Fire Rated – Maximum Safety Non-combustible rock wool core achieves A1 fire rating per GB8624-2012. Up to 4 hours fire resistance (150mm thickness); 30min (50mm), 60min (80mm). Class A surface fire resistance and Class I flame-spread classification per BSI BS476 Section 7.
Exceptional Thermal Insulation U-value as low as 0.32 W/m²·k. Reduces heating and cooling costs by up to 25%. Premium hydrophobic rock wool core (≥120kg/m³) ensures consistent thermal performance.
Superior Wind Load Resistance Grade 9 wind load resistance (highest per GB/T 15227) – withstands 12+ typhoon-force winds. Ideal for coastal and high-wind regions.
Flawless Surface Flatness Surface flatness ≤0.5mm/m eliminates oil-canning effect. Ensures a sleek, modern aesthetic that meets the highest architectural standards.
Fast & Efficient Installation Socket-and-plug interlocking dry-hung assembly with pre-embedded sealant strips. 60-80 m² per day per 10-person crew – 60% faster than aluminum veneer systems. 30% shorter construction timeline vs. traditional multi-layer facades.
Factory Direct – Source Supply 10%+ cost savings vs. traditional facade solutions. Italian production technology with original imported production line. Annual production capacity exceeds 1,000,000 m². Full logistics support with installation guidance.
RAL Classic colors (subject to design requirements)
Flame-spread Classification
Class I (BSI BS476 Section 7)
Surface Fire Resistance
Class A
Performance Feature
Technical Description
Formaldehyde Emission & Environmental Testing
Complies with the mandatory standard GB 18580-2001 "Indoor Decorating and Refurbishing Materials - Limit of Formaldehyde Emission of Man-made Boards and Their Products". Formaldehyde emission grade E1, suitable for direct indoor use.
Environmental Certification
National Commercial Standard Certification for Eco-Building Materials
High Temperature & Humidity Resistance
Tensile strength after exposure to high temperature and humidity (80°C, 80% RH, 24h) remains at 99.9% of the standard condition tensile strength.
Applicable Standards
GB/T 23932-2009 Building Insulated Sandwich Panels with Metal Facings
JG/T 453-2019 Technical Standard for Application of Metal-faced Sandwich Panels
JGJ 133-2001 Technical Code for Metal and Stone Curtain Wall Engineering
商
HP Metal Curtain Wall System
Product Overview
The HP Metal Curtain Wall System is a high-performance, factory-prefabricated insulated sandwich panel solution designed for architects, contractors, and developers seeking a balance of fire safety, thermal efficiency, structural integrity, and fast-track installation.
Engineered with a three-layer composite construction – durable metal face sheets bonded to a high-density hydrophobic rock wool core – this system consolidates structural support, thermal insulation, and aesthetic finishing into a single, ready-to-install panel. The result is a building envelope solution that significantly reduces on-site labor, shortens project timelines, and delivers long-term energy savings.
Why Choose the HP Metal Curtain Wall System?
Key Advantage
Benefit
A1 Fire Rated
Non-combustible rock wool core; up to 4 hours fire resistance (150mm); Class A surface fire rating
Thermal Efficiency
U-value as low as 0.32 W/m²·k; reduces heating/cooling costs by up to 25%
Wind Load Resistance
Grade 9 (highest per GB/T 15227); withstands 12+ typhoon-force winds
Structural Flatness
Surface flatness ≤0.5mm/m; eliminates oil-canning and deformation
Fast Installation
Interlocking dry-hung assembly; 60% faster installation than aluminum veneer systems
Factory Direct Pricing
No middlemen; cost savings of 10%+ compared to traditional facade solutions
Durability
30+ year service life; 99.9% tensile strength retention after high-humidity exposure
Design Flexibility
Custom thicknesses 50-120mm; RAL color options; PVDF/POLYESTER/LUXACOTE coatings
Core Performance Features
A1 Fire Safety – Up to 4 Hours Protection
The HP system's rock wool core is naturally non-combustible, achieving A1 fire rating per GB8624-2012. Fire resistance testing per GB/T 9978-2008 confirms:
50mm thickness: 30-minute fire resistance
80mm thickness: 60-minute fire resistance
150mm thickness: 180-minute (3-hour) fire resistance
This critical fire protection is essential for high-rise buildings, airports, factories, hospitals, and any facility where occupant safety is paramount. Unlike PE-core or aluminum honeycomb panels that soften or combust under high temperatures, the HP system maintains structural integrity during fire events.
Thermal Insulation – Reducing Energy Costs
The high-density rock wool core delivers exceptional thermal performance with thermal conductivity values ranging from 0.60 to 0.32 W/m²·k depending on panel thickness. The thermally broken aluminum frame design, featuring enclosed empty chambers, further minimizes heat conduction and prevents thermal bridging. This integrated insulation approach meets 75% building energy conservation standards, significantly reducing annual HVAC operational costs.
Structural Strength & Wind Load Resistance
The three-layer sandwich construction provides superior flexural load-bearing capacity, with test values reaching 2.5 to 5.4 kN/m² (span 2000mm). This translates to wind resistance up to Grade 9 (the highest classification per GB/T 15227), capable of withstanding extreme weather events. The rigid composite structure distributes loads uniformly, eliminating localized stress concentration and maintaining surface flatness within ≤0.5mm per meter – a critical specification for large-span facades requiring visual consistency.
Acoustic Insulation – Noise Reduction
The dense rock wool core, combined with enclosed empty chambers within the thermal break profiles, delivers effective sound deafening performance. With an airborne sound insulation rating of 38dB for 100mm-thick panels, the HP system significantly reduces external noise penetration – essential for buildings located in urban centers or near transportation corridors.
Weather Resistance & Durability
The exterior face sheet features PVDF (LUXACOTE) or POLYESTER coating systems, offering exceptional UV resistance, color retention, and corrosion protection. Accelerated aging tests confirm:
Formaldehyde emission: E1 grade (GB 18580-2001) – safe for indoor use
Expected service life: 30+ years with minimal maintenance
The fastener-free fixation system allows for thermal expansion and contraction without stress concentration, preventing buckling, delamination, or surface deformation over decades of service.
E1 formaldehyde grade; National Eco-Building Materials Certification
Thermal & Structural Performance Data
Panel Type
Thickness (mm)
Weight (kg/m²)
Thermal Conductivity (W/m²·k)
Flexural Load (kN/m², span 2000mm)
NS
60 / 80 / 100 / 120
15 / 17.6 / 20.25 / 22.9
0.60 / 0.46 / 0.38 / 0.32
2.6 / 3.7 / 4.8 / 5.7
HP
60 / 80 / 100 / 120
14.4 / 17.1 / 19.65 / 22.28
0.60 / 0.46 / 0.38 / 0.32
2.5 / 3.6 / 4.5 / 5.4
FP
60 / 80 / 100 / 120
15 / 17.6 / 20.25 / 22.9
0.62 / 0.48 / 0.40 / 0.34
2.55 / 3.65 / 4.65 / 5.55
Installation & Construction Efficiency
The HP system employs a socket-and-plug interlocking assembly method with pre-embedded sealant strips, enabling rapid on-site installation without specialized welding or complex framing. Key construction advantages include:
Factory prefabrication: Panels arrive on-site ready for installation – no separate insulation layers required
Modular dry-hung assembly: Panel clip fixation system eliminates screw penetration on the exterior surface
Installation speed: Typical crew of 10 can install 60–80 m² per day – up to 60% faster than aluminum veneer systems
Project time savings: 30% shorter construction timeline compared to traditional multi-layer facades
Single-panel replaceability: Individual panels can be removed and replaced without disturbing adjacent panels, simplifying long-term maintenance
No middlemen: Factory-direct sourcing ensures competitive pricing and supply chain transparency
Applicable Standards & Certifications
Standard
Description
GB/T 23932-2009
Building Insulated Sandwich Panels with Metal Facings
JG/T 453-2019
Technical Standard for Application of Metal-faced Sandwich Panels
JGJ 133-2001
Technical Code for Metal and Stone Curtain Wall Engineering
GB/T 15227
Test Method for Curtain Wall Air Permeability, Watertightness & Wind Load
RAL colors, panel thicknesses, coating types, and surface textures
Free Samples
Try-before-you-buy program to verify quality and specifications
24/7 Global Support
Fast response to technical inquiries, project consultation, and after-sales support
Turnkey Solutions
Complete system supply from design through installation guidance
Project Time Guarantee
30% faster installation vs. traditional systems – reduced labor and overhead
Quick Selection Guide
Step
Consideration
Recommendation
1
Fire safety critical?
Choose HP – A1 rated, 4-hour fire resistance
2
Energy efficiency required?
Choose HP – U-value as low as 0.32 W/m²·k
3
Fast-track construction?
Choose HP – 30% shorter installation time
4
Budget control?
Choose HP – factory direct pricing, 10%+ cost savings
5
Design flexibility?
Choose HP – custom RAL colors, thicknesses, coatings
For project-specific technical recommendations, design support, or sample requests, contact our engineering team directly. We respond within 24 hours to all inquiries.
